Plug & Play machine: power it up and it is ready to run.
Easy to use and extensive support provided.
Integrated laser engraving assistance:
- Preview mode: a red pointer projects on the item an exact simulation of the engraving
- Manual mode: use the joystick to line up three red pointers and set the item to the correct lasering distance.
- Automatic mode: with all parameters saved select automatic mode and watch the WeLase do the work
Class 1 laser: highest security possible.
- Built-in sensors prevent laser operation unless the door closed built with an instant cut-off should it be opened while the machine is in operation.
- A specialist glass is used on the large viewing panels to ensure a quality and safe viewing experience which can be used as standard in any store with total safety, and no need to build a cover or wear safety goggles.
- Pack jewel: WeLase becomes the perfect jewelry laser engraving machine. Interior and exterior engraving of rings, bracelets, and thin cuts of flat items Precise positioning of jewelry Contrast result, white marking, or deep engraving.
- Pack easy fix: The machine to make personalized items. Precise and fixed repeatable positioning Versatile: from a pen to a bottle with the same clamp Secure your object easily with the magnet system No clamping, no chucks, instant item positioning.
- Pack safe air: Compact laser engraver exhaust for all environments. Exhaust the fumes and particulates to keep the machine clean and accurate. Filters fumes and odors to create a safe and clean environment. Integrates easily with the WeLase. More silent than other exhausts on the market and ideal for retail space. Exhaust filters are HEPA certified.
Adapted for small to medium batches
Marking area max (L x w)
110 x 110 mm (4 x 4 in)
Max object height
Fiber: 100 mm (4 in)
3 kg (6.6 lbs)
Jewelry Laser Engraving Machine
Upgrade the WeLase with the Jewel pack to support the jeweler’s daily creations. Thanks to the rotary device, bring the final touch to your creations by personalizing the inside and outside of rings and bracelets and quickly switch to curved bangles. The WeLase can also cut metal to create thin pendants.
This will be your favorite jewelry engraver!
WeLase in Jewelry
Upgrade your Welase to offer engraving of cylindrical objects!
Rings, bracelets, jewellery, enhance your personalisation offer with engravings both on the outside and inside of the rings.
The rotary device is an essential element in the jewellers’ world.
Wobbling cutting mode
Expand your creative possibilities with our new wobbling cutting method. This spiral cutting mode improves the focus of the laser beam to cut more efficiently or thicker.
With the cutting pin table, raise your material by 2 cm. This creates an air flow underneath the plate during cutting and prevents the material from overheating.
You will avoid deformations of the material due to the heat, beam returns on the underside of the plate or colour degradation."
Make engraving easy and fun
Thanks to the camera, you can now see the marking area on your product. Design the engraving, and place it easily and quickly on the product before starting the engraving process.
G-Eye is the assistant for engraving on any flat surface (pendants, flat bracelets, pens...). You can engrave complex and irregular shapes without any worries of making a mistake.
|Max. object size (L x W x H)
|340 mm x 200 mm x 100 mm (13.4 in x 7.9 in x 3.9 in)
|Max. object weight
|3 kg (6.6 lbs)
|Up to 3000 mm/s (118,1 in/s)
|Z axis type
|Motorized & Programmable
|Marking Area - Available lenses
|F160: 110 mm x 110 mm (4.3 in x 4.3 in)
|Z axis stroke
|200mm (7,9 in)
|Communication interfaces (standard)
|Ethernet TCP/IP, Wifi, USB
|Power consumption rate
|100 - 240
|Dimensions and weights
|42Kg (92,594 lbs)
|Length x width x height
|450 mm x 560 mm x 610 mm (17.7 in x 22 in x 24 in)
|Laser safety classification
|Class 1 Door Closed / Class 2M door open (Aiming Diode)
|Lasertrace/Gravostyle/ ABC /Gravotouch
