Specifications
| Info | |
|---|---|
| Brand | OPTIMUM |
| Technical Specs | |
|---|---|
| Engine power hydraulic pump | 1.4 kW |
| Total connected load | 3.8 kW |
| Saw band speed(s) | 20 – 80 m/min |
| Saw band length | 3770 mm |
| Saw band width | 34 mm |
| Saw band thickness | 1.1 mm |
| Cutting angle from to | -45 60° |
| Dimensions and weights | |
|---|---|
| Weight | 645kg |
| Length x width x height | 2129 X 1046 X 1687 mm |
| Electrical Data | |
|---|---|
| Electrical connection | 400 V / 3 Ph ~50 Hz |
| Coolant pump motor | 0,1kW |
| Drive motor output | 3 kW |
| Mains frequency | 50 Hz |
| Cutting Range | |
|---|---|
| Cutting range 0° round (solid material) | 355mm |
| Cutting range 0° square (solid material) | 300 mm |
| Cutting range 0° rectangular upright (solid material) | 300 x 490 mm |
| Cutting range -45° round (solid material) | 290 mm |
| Cutting range -45° square (solid material) | 250 mm |
| Cutting range -45° rectangular upright (solid material) | 250 x 250 mm |
| Cutting range +45° round (full material) | 350 mm |
| Cutting range +45° square (solid material) | 290 mm |
| Cutting range +45° rectangular upright (solid material) | 290 x 340 mm |
| Cutting range +60° square (solid material) | 180 mm |
| Cutting range +60° rectangular upright (solid material) | 180 x 220 mm |
| Others | |
|---|---|
| Cutting range +60° round (solid material) | 230 mm |
