Specifications
| Info | |
|---|---|
| Brand | Larzep |
| Origin | ES |
| Technical Specs | |
|---|---|
| Material Type | Steel |
| Maximum Operating Pressure (bar) | 700 |
| Capacity (metric tons) | 30 |
| Oil Capacity (cm3) | 660 |
| Capacity (kN) | 125 |
| Collapsed Height A (mm) | 300 |
| Extended Height B (mm) | 450 |
| Return Type | Single Acting Spring Return |
| Cylinder Effective Area Advance (cm2) | 44 |
| Outside Diameter D (mm) | 120 |
| Maximum Cylinder Capacity Advance (kN) | 302 |
| Maximum Cylinder Capacity Retract (kN) | 173 |
| Stroke | 150 |
| Dimensions and weights | |
|---|---|
| Weight | 21 Kg |
