Specifications
| Info | |
|---|---|
| Brand | Chicago Pneumatic |
| Origin | JP |
| Technical Specs | |
|---|---|
| Torque Range | 500 - 2600 Nm |
| Free Speed rpm | 5000 |
| Clutch type | Pinless rocking dog |
| Min. hose diameter | 13 mm |
| Air inlet thread size | 1/2" |
| Square drive | 1" |
| Sound Pressure level | 108 dB(A) |
| Blows per minute | 650 |
| Max working torque fwd | 2100 Nm |
| Max torque reverse | 2600 Nm |
| Dimensions and weights | |
|---|---|
| Weight | 10.2 Kg |
| Length | 290 mm |
