GBP BASIC S 30320 CNC-controlled, hydraulic press brake
Standard version:
- Touch screen CNC control CybTouch 12 with 2D color interface and bending sequence calculation.
- CNC-controlled, motorized X-axis, guided on linear rails - driven by recirculating ball screws
- Safety devices FIESSLER Akas II and FMSC
- Backspace protection by means of light barrier
- CNC-controlled, motorized table crowning
- Manual height adjustment of the stop fingers (R-axis)
- Manual lateral adjustment of the stop fingers (Z-axis) on linear rail
- Two front support arms adjustable on linear rail
- Upper tool quick clamping (lateral removal)
- Standard upper tool set 135mm - 85°
- Standard die set Multi-V 85°
- Side protection doors monitored by limit switches
- Control on swivelling arm on the right side
- Electrical components from Schneider and Mitsubishi
- Hydraulic components from HAWE and Ikron
Possible equipment options:
- Controls (CybTouch 15 or Delem DA 58T)
- Extension of the X-axis to travel 1000 mm
- CNC-controlled, motorized R-axis
- Preparation for tandem operation
- Special throat size
- Additional stop fingers and front support arms
- Second foot pedal for two-man operation
- Manual or automatic central lubrication
- Air conditioning for the control cabinet
- Oil cooler
- Oil warmer
- Special tools
- Control on the left side of the machine
- Special sizes on request
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Info | |
|---|---|
| Brand | MetallKraft |
| Technical Specs | |
|---|---|
| Oil tank capacity | 400 l, 360 l |
| Dimensions and weights | |
|---|---|
| Weight | 7500 kg |
| Length x width x height | 4400 x 2200 x 3350 mm |
| Electrical Data | |
|---|---|
| Motor output | 22 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Press Brake Technical Data | |
|---|---|
| Pressing force | 320 t |
| Bending length | 3150 mm |
| Distance between columns | 2600 mm |
| Press Break Stroke | 350 mm |
| Rapid mode | 120 mm/s |
| Bending speed | 1 – 9 mm/s |
| Press Break Retraction | 90 mm/s |
| Press Break Table height | 930 mm |
| Press Break X axis stroke | 5 - 650 mm |
| Press Break X axis speed | 250 mm/s |
