HT BS BASIC S 3013 Hydraulic swing cut sheet metal shears
Standard version:
- touchscreen NC-control CybTouch 8 in swivel arm
- NC-controlled backgauge (5-1000mm) driven üvia ball screws
- safety light barrier for the back area
- motorized cutting gap adjustment üvia the control unit
- Side stop 1500mm with scale and T-slot
- Front support arms 1000mm with T-slot
- Table supports made of stainless steel with integrated transfer balls
- Hold-down device with plastic caps to protect the material
- Variable cutting length adjustment via the control unit
- Folding finger guard 1000mm with viewing glass inserts
- Sheet metal chute in the rear area
- Cutting line illumination with shadow crack
- Knives suitable for cutting stainless steel
- Upper knife with two and lower knife with four cutting edges
- Electrical components from Schneider and Mitsubishi
Equipment options:
- Adjustable angle stop
- Cutting line display by laser
- Front light barrier instead of finger protection
- Finger guard can be folded out over the entire length
- Additional front support arms
- Additional side stop on the right
- Extensions of the standard support arms, side or back stop
- Transfer ball in the side stop and the front support arms
- Servo motor for the back stop
- Manual or automatic central lubrication
- Pneumatic sheet metal holding systems
- Small parts switch with manual or pneumatic opening
- Oil cooler or oil warmer
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Info | |
|---|---|
| Brand | MetallKraft |
| Technical Specs | |
|---|---|
| Oil tank capacity | 400 l |
| Dimensions and weights | |
|---|---|
| Weight | 12,100 Kg |
| Length x width x height | 3440 x 600 x 900 mm |
| Electrical Data | |
|---|---|
| Motor output | 30 kW |
| Supply voltage | 400 V |
| Mains frequency | 50 Hz |
| Metal Shear Technical Data | |
|---|---|
| Working width | 3060 mm |
| Cutting performance material tensile strength 400 N/mm² | 13 mm |
| Cutting performance material tensile strength 700 N/mm² | 8 mm |
| Number of hold-down units | 16 St |
| Number of sheet support arms | 2 St |
| Rear stop adjustment range up to | 1000 mm |
| Rear stop speed | 120 mm/s |
| Side stop length | 1500 mm |
| Cutting angle | 1,8 ° |
| Max. strokes for full cutting length | 12 /min |
| Cutting kerf adjustment | 0.08 - 1.3 mm |
| Motor Output rear stop | 0.37 kW |
